Part Number : MDU1514

Function : 30V, 66.3A, 6.0mΩ MOSFET

Package : Power DFN56 Type

Manufactures : MagnaChip Semiconductor


Decription

The device uses advanced MagnaChip’s MOSFET Technology, which provides high performance in on-state resistance, fast switching performance and excellent quality. MDU1514 is suitable device for DC/DC Converter and general purpose applications.

MDU1514 Pinout

Switch boxing. Features

1. VDS = 30V
2. ID = 66.3A @VGS = 10V
3. RDS(ON)
< 6.0 mΩ @VGS = 10V
< 9.0 mΩ @VGS = 4.5V
4. 100% UIL Tested
5. 100% Rg Tested

Absolute Maximum Ratings (Ta = 25oC)

1. Drain-Source Voltage : VDSS = 30 V
2. Gate-Source Voltage : VGSS = ±20 V

Nch Mosfet Switch

Ordering Information

MDU1514URH -55~150oC PowerDFN56 Tape & Reel 3000 units Halogen Free

Nch Power Mosfet

MDU1514 Datasheet
